Kia Cadenza YG: Automatic Transaxle Control System / Torque Converter Control Solenoid Valve (T/CON_VFS) Components and Components Location
| Component Location |
Specification Item SpecificationControl typeN/L (Normal Low)Control pressure kpa (kgf/cm², psi)"9.81 ~ 500.14 (0.1 ~ 5.1, 1.42 ~ 72.54)"Current value (mA)50 ~ 850Coil resistance(Ω)5.
Description • Torque converter control solenoid valve is a Variable Force Solenoid (VFS) type. • When TCM supplies variable current to solenoid valve, hydraulic pressure of torque converter clutch is controlled by solenoid valve.
