Kia Cadenza: Automatic climate control system / Air Conditioning refrigerant label

Kia Cadenza YG 2016-2023 Owners Manual / Features of your vehicle / Automatic climate control system / Air Conditioning refrigerant label

■ Example

Each symbol and specification on the air conditioning refrigerant label is represented below ;

1. Classification of refrigerant
2. Amount of refrigerant
3. Classification of Compressor lubricant
4. Caution
5. Flammable Refrigerant
6. To requires Registered Technician
to Service Air Conditioning system

You can find out which air conditioning refrigerant is applied to your vehicle on the label inside of the engine compartment.

Refer to section 8 for more detail on the location of air conditioning refrigerant label.
