Inspection
1.
Turn the ignition switch OFF.
2.
Disconnect the CCV connector.
3.
Measure resistance between the CCV terminal 1 and 2.
4.
Check that the resistance is within the specification.
Specification: Refer to "Specification"
5.
Disconnect the vapor hose connected with ...
EPB Circuit Diagram
EPB connector input/output
Pin No.Description1CAN_High2CAN_Low18IGN (+)19EPB Switch Signal 121EPB Switch Signal 327EPB Switch Signal 229EPB Switch Signal 433Rear Left Motor (-)34Ground35Ground36Rear Right Motor (-)37Rear Right Motor (+)38Rear Left Motor (+)39Battery (Rear R ...
