Kia Cadenza YG: Engine Control System / Intake Air Temperature Sensor (IATS) Schematic Diagrams
| Circuit Diagram |
Specification TemperatureResistance (kΩ)°C°F-40-4040.93 ~ 48.35-20-413.89 ~ 16.030325.38 ~ 6.0910503.48 ~ 3.9020682.31 ~ 2.57401041.08 ~ 1.21601400.
Inspection 1. Turn the ignition switch OFF. 2. Disconnect the IATS connector. 3. Measure resistance between the IATS terminals 3 and 4. 4.
