Kia Cadenza YG: Parking Brake System / Parking Brake Assembly Components and Components Location
| Components (1) |
| 1. Parking brake pedal 2. Parking brake cable | 3. Equalizer assembly |
| Components (2) |
| 1. Backing plate 2. Brake shoe | 3. Shoe hold clip 4. Bolt |
Removal Parking Brake Pedal 1. Remove the main crash pad. (Refer to the Body group-crash pad) 2. Remove the cowl cross bar. (Refer to the Body group - Crash pad) 3.
