Removal
1.
Remove the fuel pump.
(Refer to Fuel Delivery System - “Fuel Pump”)
2.
Disconnect the electric pump wiring connector (A) and the fuel sender connector (B).
3.
Remove the cushion pipe fixing clip (A), and then separate the head assembly (B) from reservoir cup.
4.
Remo ...
Components
1. Drive belt2. Drive belt tensioner3. Idler4. Crank shaft pulley5. Water pump pulley
1. Oil pump chain cover2. Oil pump sprocket3. Oil pump chain 4. Oil pump tensioner assembly5. Crankshaft oil pump sprocket6. Crankshaft RH chain sprocket7. RH Timing chain auto tensioner8. RH T ...
