Kia Cadenza YG: Automatic Transaxle Control System / 35R Clutch Control Solenoid Valve(35R/C_VFS) Components and Components Location
| Component Location |
Specification Item SpecificationControl typeN/H (Normal High)Control pressure kpa (kgf/cm², psi)"500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)"Current value (mA)50 ~ 850Coil resistance(Ω)5.
Description • 35R clutch control solenoid valve is a Variable Force Solenoid (VFS) type. • When TCM supplies variable current to solenoid valve, hydraulic pressure of 35R clutch is controlled by solenoid valve.
