Kia Cadenza YG: Rear Glass Defogger / Components and Components Location
Kia Cadenza YG 2016-2021 Service Manual / Body Electrical System / Rear Glass Defogger / Components and Components Location
| Component Location |
| 1. Rear glass defogger relay (Engine room relay box) 2. Rear glass defogger switch (A/C controller) | 3. Rear glass defogger |
Inspection Wrap tin foil around the end of the voltmeter test lead to prevent damaging the heater line. Apply finger pressure on the tin foil, moving the tin foil along the grid line to check for open circuits.
