Kia Cadenza YG: Engine Control System / CVVT Oil Temperature Sensor (OTS) Schematic Diagrams
| Circuit Diagram |
Specification TemperatureResistance (kΩ)°C°F-40-4052.15-20-416.520326.020682.45401041.11601400.54801760.29
Inspection 1. Turn the ignition switch OFF. 2. Disconnect the OTS connector. 3. Remove the OTS. (Refer to "Removal") 4. After immersing the thermistor of the sensor into engine coolant, measure resistance between the OTS terminals 1 and 2.
Other information:
Kia Cadenza YG 2016-2021 Service Manual: Mode Control Actuator Repair procedures
Inspection 1. Ignition "OFF” 2. Disconnect the connector of mode control actuator. 3. Verify that the mode control actuator operates to the defrost mode when connecting 12V to the terminal 3and grounding terminal 7. 4. Verify that the mode control actuator operates to the vent mode when connecting in the reverse.
Kia Cadenza YG 2016-2021 Service Manual: Blower Resistor Repair procedures
Inspection 1. Measure terminal - to - terminal resistance of blower resistor. 2. If measure resistance isnot within specification, the blower resistor must be replaced. Replacement 1. Disconnect the negative (-) battery terminal. 2. Remove the crash pad lower cover (A) and then disconnect the connector (B).
