| Component Location |

Specification Item SpecificationControl typeN/H (Normal High)Control pressure kpa (kgf/cm², psi)500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)Current value (mA) 50 ~ 850Coil resistance(Ω)5.
Description • Line pressure control solenoid valve is a Variable Force Solenoid (VFS) type. • When TCM supplies variable current to solenoid valve, line pressure is controlled by solenoid valve.
Component Location Components 1. Heater Case (LH)2. Separator3. Evaporator Core4. Shower Duct (LH)5. Heater Core Cover6. Heater Core7. Mode Actuator8. Mode Cam9. Temp Actuator (Drive)10. Vent Door Arm11. Floor Door Arm 1. Heater Case (RH)2.
Replacement 1. Disconnect the negative (-) battery terminal. 2. Remove the heater and blower unit.(Refer to HA group – heater unit). 3. Remove the blower unit (A) from the heater unit after loosening a mounting bolt and 3 screws. Make sure that there is no air leaking out of the blower and duct joints.
