Kia Cadenza YG: Engine Control System / Crankshaft Position Sensor (CKPS) Schematic Diagrams

Kia Cadenza YG 2016-2021 Service Manual / Engine Control / Fuel System / Engine Control System / Crankshaft Position Sensor (CKPS) Schematic Diagrams

Circuit Diagram

    Wave Form

    Inspection 1. Check the signal waveform of the CMPS and CKPS using the GDS. Specification: Refer to “Wave Form” Removal 1. Turn the ignition switch OFF and disconnect the battery negative (-) cable.
