Kia Cadenza YG: Engine Control System / Heated Oxygen Sensor (HO2S) Schematic Diagrams

Kia Cadenza YG 2016-2021 Service Manual / Engine Control / Fuel System / Engine Control System / Heated Oxygen Sensor (HO2S) Schematic Diagrams

Circuit Diagram

    Wave Form

    Inspection 1. Turn the ignition switch OFF. 2. Disconnect the HO2S connector. 3. Measure resistance between the HO2S terminals 3 and 4. 4.
