Kia Cadenza YG: Engine Control System / Injector Schematic Diagrams
| Circuit Diagram |
Signal Waveform
Inspection 1. Turn the ignition switch OFF. 2. Disconnect the injector connector. 3. Measure resistance between the injector terminals 1 and 2.
