Kia Cadenza YG: Automatic Transaxle Control System / Underdrive Brake Control Solenoid Valve(UD/B_VFS) Components and Components Location

Kia Cadenza YG 2016-2021 Service Manual / Automatic Transaxle System / Automatic Transaxle Control System / Underdrive Brake Control Solenoid Valve(UD/B_VFS) Components and Components Location

Component Location

1. Underdrive brake control solenoid valve (UD/B_VFS)

    Specification Item SpecificationControl typeN/H (Normal High)"Control pressure kpa (kgf/cm², psi)""500.14 ~ 9.81 (5.1 ~ 0.1, 72.54 ~ 1.42)"Current value (mA)50 ~ 850Coil resistance(Ω)5.

    Description • Underdrive brake control solenoid valve is a Variable Force Solenoid (VFS) type. • When TCM supplies variable current to solenoid valve, hydraulic pressure of underdrive brake is controlled by solenoid valve.
