Kia Cadenza YG: Engine Control System / Variable Intake Solenoid (VIS) Valve Schematic Diagrams

Kia Cadenza YG 2016-2021 Service Manual / Engine Control / Fuel System / Engine Control System / Variable Intake Solenoid (VIS) Valve Schematic Diagrams

Circuit Diagram

    Specification ItemSpecificationCoil Resistance (Ω)30.0 ~ 35.0 [20°C(68°F)]

    Inspection 1. Turn the ignition switch OFF. 2. Disconnect the VIS valve connector. 3. Measure resistance between the VIS valve terminals 1 and 2.
