Kia Cadenza YG: Automatic Transaxle Control System / SS-B Solenoid Valve(ON/OFF) Components and Components Location
| Component Location |
Specification ItemSpecificationControl typeON/OFFCurrent value (mA)5.0 Coil resistance(Ω)10 ~ 11
Description • SS-B solenoid valve is ON/OFF type. • When TCM supplies power to solenoid valve, speed range is changed by operating the solenoid valve.
