Kia Cadenza YG: ESC(Electronic Stability Control) System / Rear Wheel Speed Sensor Components and Components Location
| Components |
| 1. Rear wheel speed sensor 2. Rear wheel speed sensor cable |
Removal 1. Remove the front wheel and tire. Tightening torque: 88.3 ~ 107.9 N.m (9.0 ~ 11.0 kgf.m, 65.1 ~ 79.6 lb-ft) 2. Remove the front wheel speed sensor mounting bolt (A).
Removal 1. Remove the rear wheel and tire. Tightening torque: 88.3 ~ 107.9 N.m (9.0 ~ 11.0 kgf.m, 65.1 ~ 79.6 lb-ft) 2. Remove the rear wheel speed sensor mounting bolt (A).
